Slim Rigid Borescopes

Pro Slim™ .165″ (4.20 mm)

The clarity and brightness of Hawkeye® Pro Slim Borescopes bring out all the details in your subject. The Pro Slim offers the best combination of small diameter, length, and bright illumination. Most machined metal parts afford ample access for the Hawkeye Pro Slim Borescope and mirror tube.

Buy Now

Slim Rigid Borescopes

Product Tube Length Model# Price
Borescope Kits
2" Pro Slim Kit 2" (50mm) PS02-NVK $1,795 Buy Now
7" Pro Slim Kit 7" (180mm) PS07-NVK $1,795 Buy Now
12" Pro Slim Kit 12" (305mm) PS12-NVK $1,895 Buy Now
17" Pro Slim Kit 17" (435mm) PS17-NVK $1,995 Buy Now
22" Pro Slim Kit 22" (560mm) PS22-NVK $2,395 Buy Now
Borescope Only
2" Pro Slim Borescope 2" (50mm) PS02 $1,195 Buy Now
7" Pro Slim Borescope 7" (180mm) PS07 $1,195 Buy Now
12" Pro Slim Borescope 12" (305mm) PS12 $1,295 Buy Now
17" Pro Slim Borescope 17" (435mm) PS17 $1,395 Buy Now
22" Pro Slim Borescope 22" (560mm) PS22 $1,795 Buy Now
Mirror Tubes
2" Pro Slim Mirror Tube 2" (50mm) PS-MT02 $215 Buy Now
7" Pro Slim Mirror Tube 7" (180mm) PS-MT07 $200 Buy Now
12" Pro Slim Mirror Tube 12" (305mm) PS-MT12 $210 Buy Now
17" Pro Slim Mirror Tube 17" (435mm) PS-MT17 $220 Buy Now
22" Pro Slim Mirror Tube 22" (560mm) PS-MT22 $260 Buy Now

Download Pricing Table

Borescope Pro Slim Rigid

Pro Slim™ .165″ (4.20 mm)

The clarity and brightness of Hawkeye® Pro Slim Borescopes bring out all the details in your subject. The Pro Slim offers the best combination of small diameter, length, and bright illumination.

Most machined metal parts afford ample access for the Hawkeye Pro Slim Borescope and 90º DOV mirror tube. You will clearly see burrs and surface finish in bores and cross-holes.

Hawkeye Pro Rigid Borescopes contain:

  • Our latest endoGRINs® image relay lenses
  • Multicoated objective lens
  • LightConcentrator™ light post
  • Independent focusing ring for convenient video and still photography
  • A Super bright, portable SuperNOVA™ Light, with rechargeable SuperNOVA Lithium-Ion batteries, and a rugged Hawkeye Carrying Case are included with Kit purchases.



Hawkeye® Pro Slim Specifications

Optics
Field-of-View 42°
Direction-of-View Direction of View: 0°, 90° (with Mirror Tube adaptor)
Relay Optics e2 endoGRINs® Glass Relay Lenses
Magnification Borescopes are not fixed magnification like microscopes. See chart.
Mechanical / Construction
Length 7", 12", 17", 22"
Diameter Scope: .165" (4.20 mm), w/ Mirror Tube: .188 (4.80 mm)
Lightpost LightConcentrator™ ACMI configuration, Diameter 0.300"
Eyecup Standard DIN, 32 mm diameter, with independent focusing ring
Materials
Tube 304 Stainless Steel
All Machined Stainless Steel 303 Stainless Steel
Eyecup and Focusing Ring Aluminum, black anodized
Front Window AR coated optical Glass
Illumination Fiber Optical Glass
Relay Optics e2 endoGRINs® gradient index glass lenses
Environmental
Temperature Range Official - 20° to 120° C.
Note 1 Hawkeye Pro Rigid Borescopes can be made to operate up to 300 deg. C on a custom Basis. Contact your sales representative for details.
Note 2 These scope were not designed to operate below 0°. However, several of our customers have successfully used the scopes in liquid Nitrogen at 77 deg. K.
Pressure All Hawkeye borescopes we designed only for use at ambient pressure, however, we have several customers who have successfully used Hawkeye Borescopes at pressures up to 500 PSI and down to 10-6 Torr. As the scopes were not specifically designed for this, the operator does so at his own risk.
Chemical Resistance All Hawkeye Pro Rigid borescopes (tube only, not the eyepiece end) are water tight and are resistant to most hydrocarbons; oils, gasoline, hydraulic fluid, jet fuel, etc. Exposure to Acids and strong Alkali should be avoided as it will attack the optical window.

Download Specifications
